规格参数：
型号 | 额定电压V | 额定功率W | 额定转矩NM | 峰值转矩NM | 额定电流Arms | 峰值电流Arms | 额定转速rpm | 最高转速rpm | 转动惯量 10^-4kg m^2 | 电机总长(L)mm |
SY40D00530M3/M5/C4015-24V | DC24 | 50 | 0.16 | 0.48 | 3.2 | 9.6 | 3000 | 4000 | 0.035 | 57.5 |
SY40D00530M3/M5/C4015-48V | DC48 | 50 | 0.16 | 0.48 | 5.5 | 16.5 | 3000 | 6000 | 0.035 | 57.5 |
SY40D00530M3/M5/C4Z15-24V | DC24 | 50 | 0.16 | 0.48 | 3.2 | 9.6 | 3000 | 4000 | 0.035 | 88.5 |
SY40D00530M3/M5/C4Z15-48V | DC48 | 50 | 0.16 | 0.48 | 5.5 | 16.5 | 3000 | 6000 | 0.035 | 88.5 |
SY40D01030M3/M5/C4015-24V | DC24 | 100 | 0.32 | 0.96 | 5.5 | 16.5 | 3000 | 4000 | 0.069 | 72 |
SY40D01030M3/M5/C4015-48V | DC48 | 100 | 0.32 | 0.96 | 5 | 16.5 | 3000 | 6000 | 0.069 | 72 |
型号 | 额定电压V | 额定功率W | 额定转矩NM | 峰值转矩NM | 额定电流Arms | 峰值电流Arms | 额定转速rpm | 最高转速rpm | 转动惯量10^-4kg m^2 | 电机总长(L)mm |
SY40D01030M3/M5/C4Z15-24V | DC24 | 100 | 0.32 | 0.96 | 5.5 | 16.5 | 3000 | 4000 | 0.069 | 103 |
SY40D01030M3/M5/C4Z15-48V | DC48 | 100 | 0.32 | 0.96 | 5 | 16.5 | 3000 | 6000 | 0.069 | 103 |
